36V 180W Brushless DC Servo Motor 0.6N.m 3400RPM Φ57mm for Inkjet Printers
36V 180W Brushless DC Servo Motor 0.6N.m 3400RPM Φ57mm for Inkjet Printers
Servo Motor Specification
Part Number:57JSF1830P
Phase:3 phase
Power Supply Voltage:36V
Rated Power:180W
Rated Torque:0.6N.m(84.96 oz.in)
Peak Torque:1.71N.m
Rated Speed: 3400RPM
No Load Speed:5300RPM
Rated Current:8.8A
Poles:4;
Encoder:1000 Lines
Physical Specifications:
Frame Size:Φ57mm
Body Length:163.5mm
Shaft Diameter:8mm
Shaft Length:30mm
Weight:1.2kg;
.jpg)
.jpg)
Wholesale stepper motors and wholesale stepper motor drivers online with guaranteed quality and competitive price at Oyostepper.com!
| Servo Motor Specification | |
|---|---|
| Rated Current | 8.8 |
| Number of Phase | 3 Phase |
| No-load Speed | 5300 |
| Power supply voltage | 36 |
| Encoder | 1000 Lines |
| Motor Base | Φ57 |
| Servo Motor Type | DC Servo Motor |
| Rated Power(W) | 180 |
| Rated Speed(rpm) | 3400 |
| Rated Torque(Nm) | 0.6 |
| Peak Torque(Nm) | 1.71 |
| With Brake | Without brake |
